Thiết bị cắt sét đường Video FL-BNC


Lượt truy cập: 170 Lượt xem

Model : FL-BNC

Thiết bị cắt sét đường Video FL-BNC

IEC61000-4-5 and ITU-TK20&K21 are the recognized standards for top quality surge protectors, FL-BNC made by the high response surge arresters, the advantage is allowed clamping voltage and low loss against high speed signal, because it had a low capacitance. Designed to protect the equipment and coaxial line, connect in series. Interface accord with BNC standard.

1. IEC61000-4-5 and ITU-TK20&K21
2. Clamping voltage and low loss against high speed signal
3. Low capacitance. Designed to protect the equipment and coaxial line, connect in series
4. Interface accord with BNC standard

Coaxial signal: IEC6100-4-5 and ITU-TK20&21
Nominal discharge current(In):5 KA(8/20μS)
Working voltage: 0-2V
Limit voltage: ≤30V
Apply Band rate: 10Mbps
Connector: BNC
Insert consumption: ≤0.5dB
Delay time: ≤10ns
Working temperature:-20 to 60°C
Storage temperature:-25 to 85°C
Humidity: Relative humidity 5% to 95%
No power supply needed, No consumption
RACK protect: 9,12,16,24 choice
L×W×H: 72mm×42mm×25mm
Shell: Alnico
Color: Blue
Weight: 10g
Warranty: 3 years
Approvals: FCC,CE, RoHS approvals

kt12

fl-bnc-usermanual

fl-bnc-datasheet

FL-BNC:
BNC video lightning protector, 4500V protection
