Bộ chuyển đổi 1 cổng RS-232/485/422 sang Ethernet NP301

6.015 lượt xem

Adopt 32 bit ARM processor

Support 3-in-1 RS-232/RS-485/RS-422 serial interface

Support 10/100M

Support 300bps-115.2Kbps

Support TCP, UDP, ARP, ICMP, HTTP and DHCP protocol

Support across gateway, router communication

Support standard TCP/IP SOCKET

Support Windows serial interface driver mode

Support Virtual serial driver access and auto connect once the network disconnect

Support network and serial interface configuration mode

Low consumption design

Support DIN-Rail or wall mounting installation

Working termperature: -40～75℃

Yêu cầu báo giá

Giới thiệu

Bộ chuyển đổi 1 cổng RS-232/485/422 sang Ethernet NP301

NP301 serial device server is designed to make your serial devices internet ready instantly. It provides 1 port RS232/485/422 (RS232, DB9M; RS485/422, 5 bit terminal block) and 1 port 10/100Base-T(X).It makes them ideal choice for connecting decentral serial devices and Host computer to an IP based Ethernet, making it easily and conviniently for your management. Its software can be setting and updating by serial program group in the application. It supports TCP, UDP, ARP, ICMP, DHCP and Windows Native COM, LLF functions.
What’s more, NP301 serial devices server provides powerful management configuration tools based on Windows, guiding users’ configuration of the devices step by step. All configurations can be done by network and serial port, supporting communication across gateway and router. In addition, it allows users to configurate flexibly IP address, Server or Client mode, size of packet, etc.
NP301 serial device sever is designed with EMC protection, and power supply have overcurrent and overvoltage protection. These make it woking stably in hazardous environment.
Easy wall and DIN-Rail mounting

Thông số kỹ thuật

LAN：
Standard: 10Base-T，100Base-TX
Protocol: Support TCP, UDP, APR, ICMP and DHCP protocol
Signal: Rx+,Rx-,Tx+,Tx-
Speed: 10/100Mbps
Working: Full-duplex and half-duplex
Working mode: Support Server and Client
Transmission; 100m
Connector: RJ45

Serial interface:
Serial interface number: 1 port RS-232,1 port RS-422/485
RS-232 signal: TXD,RXD,RTS,CTS,DTR,DSR,GND
RS-422 signal: T+（A）,T-(B),R+(A),R-(B),GND
RS-485 signal: D+（A）,D-(B),GND
Parity bit: None,Even,Odd,Space,Mark
Data bit: 5bit,6bit,7bit,8bit
Baud rate: 300bps～115200bps
Flow control: RTS/CTS or XON/XOFF
Direction control: RS485 side adopt ADDC technology, auto text and control data transfer direction
Loading: RS-485/422 side support 32 nodes (customize 128 nodes) loopback
Transmission: RS-485/422 side 1200m; RS-232 side 15m
Interface protection: 1500W surge protection, 15KV static protection
Interface type: RS-232 side DB9 male，RS-485/422 side 5 bit terminal block

Power supply:
Power input: 12VDC(9~48VDC)
Consumption: Approx 1.4W

Environment
Working temperature:-40°C～75°C
Storage temperature:-40°C～85°C
Humidity: Relative humidity 5% to 95%

Appearance
Color: Black and Blue
L×W×H: 100mm×69mm×22mm
Material: Iron (Shell)
Weight: 530g

Warranty: 3 years
Approvals: FCC, CE, RoHS approvals
